EnviroCB – Recovered Carbon Black
High quality recovered carbon black from End-of-Life-Tyres
Enviro recovers the valuable carbon black (CB) materials from the End-of-Life Tyres (ELT). The selected mix of tyre material defines the properties of the recovered Carbon black materials (rCB). Enviro’s technology has proven consistency in quality since 2016 and replacing up to 100 percent of virgin Carbon black in a variation of rubber applications. Today Michelin is even using the material in MotoE racing tyres. The rCB also contains less Polycyclic aromatic hydrocarbon, PAH, than CB.
Recovered Carbon Black from Enviro
- Works excellent for substitution of vCB up to 100 percent in numerous applications. All type of rubber applications, tyres, plastics and pigments.
- Proof of concept: multiple buyers such as Anva Polytech, Trelleborg, Hexpol and Michelin.
- Our patented technology secures high quality and consistency.
- Full analysis according to ASTM per batch (COA per batch).
- Minimum 9000 mT rCB per plant.
- Packaging type: Bigbags, bulk and potentially small bags (meltable).
Advantage to Virgin Carbon Black
- No connection to oil price.
- Extremely low PAH content.
- Huge CO2 footprint reduction (approx 80 percent compared to virgin CB).
- Long-term price agreements (fixed or connected to other commodity).
- First mover advantage – opportunity to secure large volumes via off-take.
- Ongoing further development of our rCB’s. Improved dispersion properties.
Global tyre manufacturer Michelin has presented a sustainable racing tyre based on recovered carbon black from Scandinavian Enviro Systems. The tyre contains of 46 percent renewable and recovered material.
As the first company in the world Enviro has recieved ISCC certification for recovered carbon black
In accordance with the completed ISCC certification, the use of recovered carbon black from Åsensbruk, compared with the use of the corresponding amount of virgin carbon black, will lead to a reduction in carbon emissions of a full 93 percent.
Uses of carbon black
Carbon black, is the first commercial nano-material, and comes in a variety of grades depending on the end application. 90% of all carbon black produced is used in rubber applications where it acts as a reinforcing filler. Furthermore, carbon black is also used as a black pigment in everything from plastics to mascara. Carbon black is also electrically conductive and can therefore be used to handle static electricity. Moreover, the addition of carbon black gives UV-protection to a material and reduces the need for UV-protective additives. Enviro’s focus is to recover carbon black first of all for re-use as a reinforcing filler in rubber materials.
Enviro and Michelin
Tyre manufacturer Michelin has produced a new racing tyre, comprising between 33 and 40 percent recovered material, ahead of the MotoE World Cup motorcycle racing series. The new and more sustainable racing tyre contains, among other materials, recovered carbon black that was produced using Enviro’s recycling technology for end-of-life tyres.
Michelin’s new racing tyres has better performance and less climate impact due to recovered carbon black from Enviro
The global trend towards renewable materials
Demand for rapid transformation to sustainability from leading investors forces tyre and rubber industries to act and move forward with updated strategies, legal requirements as well as addressing public opinion. All driving forces are directed in the same direction. Tyre companies in the world account for 74 percent of carbon black consumption (tot value US23 billion)
Carbon Black Market
The global demand is estimated to 16,5M ton for 2021. The estimated value only to the tyre producers is about 23bUSD and they consume about 74% of all carbon black. Each full-scale Enviro plant produce about 9 000 ton rCB per year.
The carbon black market is expected to grow by 8,8% per year, to a market value of by USD 30bn by 2023.
The demand of rCB exceeds the supply
- Estimated substitution rate of 38 percent (virgin carbon black) equals >800 full scale plants
- 160 full scale plants are needed to reach a 20 percent market share
Market size. Forecasted global consumption of carbon black 2018–2023 (bn USD)
Download our EnviroCB – flyer
Unique patented CFC-pyrolysis technology
The unique patented CFC*-pyrolysis technology, upon which Enviro’s full-scale plant is built, gives a high quality recovered Carbon Black product from end-of-life tires. The high quality is to a large extent correlated to what degree the oil is driven away from the tire chips during pyrolysis, which is a type of dry distillation in an oxygen free atmosphere.
First key evidence that the pyrolysis has been successful is the result from the transmittance of toluene extract test showing that all oil residues have been driven out, leaving a completely odor-free product. The surface area and oil absorption number (OAN) are consistent and show low variability. The final evidence of the high quality is the evidence that the recovered carbon black can be re-used in rubber compounds. As the EnviroCB™ is replacing 100% virgin N550 in several commercial rubber applications this is a true proof of concept. All the major customers are delivering to the global market. The price of carbon black is correlated with the world market price of crude oil, which has increased by several folds over the past 20 years.
Carbon black grades in the recovered product
Virgin carbon black is produced with various sophisticated methods, the most common nowadays being the furnace process. Depending on the properties required in the rubber material there are a variety of different carbon black grades to choose from. The pyrolysis technique does not create any new carbon black, but recovers the original range of carbon black grades that were in the tire rubber, from N110 up to N772. Any carbon black product from ELT –pyrolysis would therefore have the innate property of being a mixture of the inherent grades.
Properties of re-cycled carbon black
Approximately 30 percent of the tire is made up of carbon black which is recovered in the pyrolysis. After pyrolysis there are several post-processing steps where the steel and textile are separated from the carbon black. The carbon black is then milled to ensure correct particle size distribution. Virgin carbon black also form micro sized particles coming from agglomerates of the small nano-sized primary particles.
Carbon black grades differ mainly by the surface area and the structure. The surface is re-exposed after pyrolysis and milling. All in all, the carbon black from a controlled mixture of end-of life passenger car and truck tires pyrolyzed by Enviro is today replacing virgin carbon black (N550) up to 100% in commercial applications which is a true proof of concept. Enviro continues to develop and widen its range of quality carbon black products, primarily via choice of raw material source.
Approximately 1.5 to 2 kg of crude oil is needed in order to produce 1 kg of virgin carbon black. Replacing the virgin carbon black with recovered carbon black reduces the carbon foot print to a corresponding extent
Recovering carbon black also mean re-using precious raw material, thus moving higher up the recycling hierarchy.
In addition, the process of producing the recovered material has significantly lower CO2 footprint compared to traditional furnace process.
A growing carbon black market
Asia is currently the largest producer and consumer of carbon black, accounting for about 55 percent of global production and consumption according to 2010 figures. China accounts for nearly half of Asian consumption. The majority of the increase in carbon black production capacity expected to come about in the next five years will come out of Asia, with China leading the way. The growth in carbon black production is closely linked to the automotive industry and to tyre production. The fact that more and more global automotive production is moving to China, India and Eastern Europe is prompting the tyre industry, and therefore also carbon black producers, to follow.
There is a steady trend toward concentration and consolidation among carbon black producers. Petroleum companies have scaled back their production of carbon black, and the sector is now dominated by chemical companies whose main product is carbon black. All the major producers are global players. The price of carbon black is correlated with the world market price of crude oil and vary over time.
The recovered carbon black from our process is less impacted by the crude oil price volatility and able to keep a more stable value over time.
